1800 KN PET Preform Injection Molding Machine 5 Ejector Point , machine with special packing / 180 ton molding machine

Ningbo Haijiang Machinery Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

1800 KN PET Preform Injection Molding Machine 5 Ejector Point , machine with special packing / 180 ton molding machine

  • 1
  • 2

Brand Name : taihong

Model Number : HJF780

Certification : ISO9001

Place of Origin : China

MOQ : 1

Payment Terms : TT, L/C, Western Union

Supply Ability : 500sets/month

Delivery Time : 25 days

Packaging Details : Export Standard

Price : USD 10000 /SET

Shot Weight300rams : 264/317/375grams

Ejector Point : 5

Machine Dimension : 4.85m*1.3m*2.1m

Tie bar : 470*470mm

Table height : 800mm

Capacity : 10-15 cartoon/min

Contact Now

1800 KN PET Preform Injection Molding Machine 5 Ejector Point 4.85m*1.3m*2.1m , machine with special packing

1800 KN PET Preform Injection Molding Machine 5 Ejector Point , machine with special packing / 180 ton molding machine

Main Features

Enlarged hydraulic system and pump servo motor.

Enlarged the torque of the plasticization motor.

Enlarged ejector force.

Advance injection screw design for PET.

Chrome plated injection screw and barrel flange.

Leading technology and performance.
China unique producer, central locking toggle.
Injection molding compounders (CIML) fill the blank in Asia.
Electro-hydraulic hybrid 2 platen machines are special for automotive industry with the leading level.

FAQ
1: Q:All of your products are made by yourself or purchasing the others?
A:We have independent technical team who focus on making machines, all the products
are made by our technical team.
2: Q:What is the ability of your factory?
A:About injection molding machine, we could produce 50 sets machines per month.
about blow molding machine, we could produce 30sets machine per month
3:Q:Do you have any technical supports about your products?
A:We have had long term collaboration with our partners worldwide, and we have a lot
of cooperation with a lot hef advanced manufacture company on the world.
4:Q:Do you have any other service about your products?
A:We have a lot of experience on making complete "Turn-Key" projects and
specifications for our clients. Also we have a fixed service system.
5:Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied with us
at first.
1800 KN PET Preform Injection Molding Machine 5 Ejector Point , machine with special packing / 180 ton molding machine
Specification

Injection Unit UNIT A B C D
Screw diameter mm 90 95 105 110
Screw L/D ratio L/D 23.2 22 19.9 19
Shot size(theoretical) CM³ 2924 3258 3981 4369
Injection weight(ps) g 2632 2933 3583 3932
Injection rate g/s 574 640 781 858
Injection pressure Mpa 195 175 143 130
Screw speed rpm 115
Clamping Unit
Clamp tonnage KN 7800
toggle Stroke Mm 950
Space Between tie Bars mm 980*950
Max.mold height mm 960
Min.mold height mm 400
Ejector Stroke Mm 280
Ejector tonnage KN 186
Others
Max.pump pressure Mpa 16
Pump motor power KW 37+30
Heater power kw 56.7
Machine size(L x W x H) m 11.43*2.4*3.14
Machine weight Ton 37
Oil tank capacity L 1500


1800 KN PET Preform Injection Molding Machine 5 Ejector Point , machine with special packing / 180 ton molding machine

1800 KN PET Preform Injection Molding Machine 5 Ejector Point , machine with special packing / 180 ton molding machine
